Concrete Kerb Paver Machines
Leading Manufacturers, Exporters, Wholesaler, Retailer of Concrete Kerbing Machine, Kerb Paver Machine, kerb laying machine and Kerb Casting Paver from Mahesana.
| Business Type | Manufacturer, Exporter, Supplier, Retailer |
| Country of Origin | India |
| Type | Concrete Kerbing Machine |
| Certification | ISO 9001:2008 |
| Color | Black, |
| Condition | New |
| Automatic Grade | Semi Automatic |
| Warranty | 1year |
| Brand Name | RANKER INDIA |
| Application | Concrete Kerbing |
| Weight | 1000KG |
| Power | DIESEL |
CONCRETE KERBING MACHINES
KERB PAVER
KERB LAYING MACHINES
SMALL MINI KERB DIVIDER MACHINES.
- 400MM X 400MM (L X H) SIZE KERBING
- SEMI AUTOMATIC
- DIESEL ENGINE /PETROL ENGINE BASE
- SENSING FACILITIS
- SUITABLE ROAD CONSTRUCTION WORKS
| Business Type | Manufacturer, Exporter, Supplier, Retailer |
| Type | Kerb Paver Machine |
| Certification | ISO 9001:2008 |
| Color | Grey |
| Condition | New |
| Automatic Grade | Automatic |
| Driven Type | Hydraulic |
| Warrenty | 1 Year |
| Brand Name | Ranker India |
We are supplier of this Kerb paver machine with 16HP Petrol Engine based.
| Business Type | Manufacturer, Exporter, Supplier, Retailer |
| Type | Kerb Laying Machine |
| Certification | ISO 9001:2008 |
| Application | Construction Use |
| Color | Grey |
| Condition | New |
| Automatic Grade | Semi Automatic |
| Driven Type | Mechanical |
| Warranty | 1year |
| Engine Power | 0-20BHp |
| Weight | 800-900kg |
| Engine | 16 Hp Petrol Engine |
| Steering Control | Auto/manual |
| Height Control | Auto/Manual |
| Hydraulic Pump | Variable Displacement Axial Pump |
| Drives Main Drive | Duplex Chain / Hydraulics- V Belt |
| Solenoid Valves | 12 V Dc |
| Compaction Method | By Ramming Mechanism |
| Minimum Radious of Kerb | 2.4 Mtr |
| Laying Capacity (W X H) | 600 X 500 Mm Max. & 175 X 500 |
| Laying Speed | 80 Mtr /hour ( Continuous Feeding Material) |
| Stroke / Min | 25 Max. |
| Size Of Tyres | 4.00 X 8.00 (6 Ply - 4 Nos.) |
| Diesel Tank Capacity | 8.5 Ltrs |
| Hydarulics Tank Capacity | 6.5 Ltrs |
| Slump Range | Zero Slump |
| Details of Vibrators | Nil |
| Fuel (diesel ) Consuption | 1.6 Ltrs Diesel / Hour |
| Length ( Without Mould ) | 1945 Mm |
| Lenghth ( with Mould ) | 2715 Mm |
| Brand Name | Ranker India |
| Port | Any India Port |
| Payment Terms | L/C, D/A, D/P, T/T |
| Delivery Time | 06 to 07 Days |
| Packaging Details | Open |
- Rate :6,00,000/-Rs. +18% GST +Freight
- NOTE : One Kerb Mould, String line assembly , Tools kit..etc with machine.
- For detail offer call on this Phone NO : +91 99094 95508, Email : info@rankerindia.com
- Quotation Validity : 15 Days only.
- Subject to Mehsana, Gujarat jurisdiction only.
- others terms will clear to you in final proforma Invoice.
| Business Type | Manufacturer, Exporter, Supplier, Retailer |
| Brand Name | Ranker India |
| Condition | New |
| Color | Grey |
| Certification | ISO 9001:2008 |
| Type | Kerb Paver Machine |
| Driven Type | Hydraulic |
| Automatic Grade | Semi Automatic |
| Delivery Time | 7 days |
We are manufacturing & trading the all type of the Kerbing Paver & Kerb Paver's spare-parts. We are maintain the spares for the KP:40, Kp1200. etc. famous model used. We are trading the Kerb Paver Diesel Engine & petrol Engine based. It's very successfully model in Indian market.
