Visnagar, Mahesana, Gujarat
- GST NO. : 24AAMFR4364A1ZE
Kerb Cutter ( Divider Cutter)
Leading Manufacturers, Exporters, Wholesaler, Retailer of Concrete Divider Cutter, Kerb Cutter with Cutting Blade and Kurb Cutting Machine from Mahesana.
| Business Type | Manufacturer, Exporter, Supplier, Retailer |
| Type | Road Cutter Machine |
| Certification | ISO 9001:2008 Certified |
| Color | Light White |
| Automatic Grade | Semi Automatic |
| Condition | New |
| Place of Origin | India |
| MODEL | 01 |
| Engine Type & Power | 5 HP Diesel Engine Greaves |
| Transmission | V Belt Drive |
| Blade Size | 50 x 610 x 5mm( 24 |
| Cutting Method | Rack & Pinion ( Up & Down,Forward & Reverse ) |
| Water Tank Capacity | 100 ltr. |
| Cutting Size | Max. Height 500 mm x width 175 mm |
| Cutting Speed | Max. 50 to 60 cuts per hour |
| Overall Dimension | 1500 x 1450 x 2000 mm |
| Tyre Size | 3.50 x 8 ( Adjustable- all direction ) |
| Brand Name | Ranker India |
01) 05hp diesel engine greaves make-rope start model
24" inch diamond cutting blade fitted .
rate : 98,500/-rs. +18% gst +freight
02) 10hp diesel engine greaves make -rope start model
28" inch cutting blade fitted
rate : 1,25,500/-rs. +18% gst +freight
03) 10hp diesel engine greaves make -self start model
32" inch cutting blade fitted
1,35,500/-rs. +18% gst +freight
-engine : 05hp/10hp diesel engine (rope start/electric start)
- engine company :greaves make diesel engine
- cutting blade size :24" inch to 32" inch suitable.(blade cost extra if choose above 24" inch)
- transmission : v belt drive
- cutting method:rack & amp; pinion(forward & amp reverse )
- plastic water tank capacity :100 ltr. ( sintex make)
- engine company :greaves make diesel engine
- cutting blade size :24" inch to 32" inch suitable.(blade cost extra if choose above 24" inch)
- transmission : v belt drive
- cutting method:rack & amp; pinion(forward & amp reverse )
- plastic water tank capacity :100 ltr. ( sintex make)
| Business Type | Manufacturer, Exporter, Supplier, Retailer |
| Country of Origin | India |
| Certification | CE Certified |
| Weight | 185 Kg |
| Color | Grey, Light White |
| Condition | New |
| Automatic Grade | Semi Automatic |
| Driven Type | Mechanical |
| Warranty | 1year |
| Blade Size | 300-600mm |
| Cutting Depth | 4 inch to 12 inch |
| Engine Power | 8.4 hp Air Cool Diesel Engine |
| Rated Speed | 1750r/min(rpm) |
| Brand Name | Ranker India |
KERB CUTTER /CONCRETE KERB CUTTER MACHINES
- 05HP DIESEL ENGINE -ROPE START MODEL WITH 24" BLADE
- 10HP DIESEL ENGINE -ROPE START/SELF START WITH 32" BLADE
- READY TO USE DESIGNED
- BLADE SUITABLITY : 14" TO 32" SIZE
- ENGINE TOOL KIT & MANUAL
- 04 TYRE , 02 TYRE STERING ROTATION POSSIBLE
| Business Type | Manufacturer, Exporter, Supplier, Retailer |
| Certification | ISO 9001:2008 |
| Color | Grey |
| Condition | New |
| Automatic Grade | Manual, Semi Automatic |
| Warrenty | 1Year |
| Type | Diesel Engine Based |
| Brand Name | Ranker India |
| Application | Concrete Curb Cutting Process |
| Power Source | Diesel |
| Warranty | 1 Year In Genuine Case* |
| After-Sales Service Provided | Yes |
we are manufacturing the 05hp, 8.5hp & 10hp diesle engine based kerb-curb -divider cutting machine with rope start & self start mode. We are fitting the 24" to 32" inch dimaond cutting balde in machine.
tehcnical specification :
- transmission : v belt drive.
- blade size: 20" to 32" inch (diamond cutting blade)
- cutting method :rack & pinion
- water tank capacity :100 ltr. (sintex make)
- cutting size max. :7" inch to 11" inch.
- cutting speed max.: 50 to 60 cuts per hour
- tyre/ wheel :04 nos.
